ROYAL DOUBLE BUBBLE 04006
Harmonization Code : 3214.10.00 | Putty and other mastics | Resin cements, caulking compounds and other mastics
Main features
- Low-Viscosity Thin-Bondline Flow
- Extended 45-Minute Working Window
- Progressive Room-Temperature Strength Build
Product Description
Hardman Double/Bubble 04006 Regular-Setting Epoxy combines a 3.5 g premeasured dual-pouch format with a low-viscosity, two-part epoxy for thin glue lines. The light-amber mixed adhesive has a viscosity of 3,700 cP at 25 deg C, a 45 minute work time, and a 4 hour handling time. It sets in a 10 mil film at room temperature and develops typical lap shear strength from 500 psi after 3 hours to 2,900 psi after two weeks on acid-etched aluminum. The cured material reaches 78 Shore D hardness and is used for furniture, hobby, and sports-equipment repair on supported aluminum, epoxy, phenolic, and wood surfaces.
Key features
- Thin glue-line flow: The 3,700 cP mixed viscosity is suited to a 10 mil adhesive film.
- 45-minute work time: The defined working window supports placement before the 4 hour handling stage.
- Progressive room-temperature strength: Lap shear rises from 500 psi after 3 hours to 2,900 psi after two weeks on acid-etched aluminum.
Applications
Applications include thin glue-line bonding and repair for furniture, hobby projects, and sports equipment using supported aluminum, epoxy, phenolic, and wood surfaces.
TDS, SDS & Technical Documents
Technical Specifications
Thermal Properties
Additional Information
As supplied / before processing
| Property | Value | Unit | Method / condition |
|---|---|---|---|
| Package size | 3.5 | g | Premeasured dual-pouch packet |
| Color | Light amber | - | Part A, Part B, and mixed adhesive |
| Mixed viscosity | 3,700 | cP | At 25 deg C |
| Work time | 45 | min | At room temperature |
| Tack-free time | 60 | min | At room temperature |
| Handling strength | 4 | h | At room temperature |
| Shelf life | 24 | months | Part A and Part B |
After processing / final state
| Property | Value | Unit | Method / condition |
|---|---|---|---|
| Hardness | 78 | Shore D | Tested at 25 deg C |
| Impact strength | 6.7 | ft-lb | Tested at 25 deg C |
| Maximum service temperature | 52 | deg C | Cured adhesive |
| Lap shear strength | 500 | psi | Acid-etched aluminum-to-aluminum; 3 h cure at 25 deg C |
| Lap shear strength | 2,000 | psi | Acid-etched aluminum-to-aluminum; 24 h cure at 25 deg C |
| Lap shear strength | 2,900 | psi | Acid-etched aluminum-to-aluminum; 2 week cure at 25 deg C |
